GSK-3β (IC50 = 6.7 nM); GSK-3α (IC50 = 10 nM); cdc2 (IC50 = 8800 nM)

CHIR-99021 shows greater than 500-fold selectivity for GSK-3 versus its closest homologs CDC2 and ERK2, as well as other protein kinases. CHIR-99021 exhibits only modest inhibition of 23 nonkinase enzymes and only weak binding to a panel of 22 pharmacologically significant receptors. In CHO-IR cells that express the insulin receptor, CHIR-99021 causes the activation of glycogen synthase (GS) with an EC50 of 0.763 μM[1].

In a rodent model of type 2 diabetes, oral administration of CHIR-99021 at 30 mg/kg improves glucose metabolism. Three to four hours after oral administration, the maximum plasma glucose reduction—roughly 150 mg/dl—occurs, and plasma insulin levels stay at or below control. In ZDF rats, oral administration of CHIR-99021 at doses of 16 or 48 mg/kg an hour prior to oral glucose challenges significantly improves glucose tolerance, with plasma glucose levels falling by 14% and 33% at the 16 mg/kg and 48 mg/kg doses, respectively. The higher dose of CHIR-99021 also lessens hyperglycemia prior to the oral glucose challenge[1].

All kinase assays followed the same core protocol with variations in peptide substrate and activator concentrations described below. Polypropylene 96-well plates were filled with 300 μl/well buffer (50 mmol/l tris HCl, 10 mmol/l MgCl2, 1 mmol/l EGTA, 1 mmol/l dithiothreitol, 25 mmol/l β-glycerophosphate, 1 mmol/l NaF, 0.01% BSA, pH 7.5) containing kinase, peptide substrate, and any activators. Information on the kinase concentration, peptide substrate, and activator (if applicable) for these assays is as follows: GSK-3α (27 nmol/l, and 0.5 μmol/l biotin-CREB peptide); GSK-3β (29 nmol/l, and 0.5 μmol/l biotin-CREB peptide); cdc2 (0.8 nmol/l, and 0.5 μmol/l biotin histone H1 peptide); erk2 (400 units/ml, and myelin basic protein-coated Flash Plate [Perkin-Elmer]); PKC-α (1.6 nmol/l, 0.5 μmol/l biotin-histone H1 peptide, and 0.1 mg/ml phosphatidylserine + 0.01 mg/ml diglycerides); PKC-ζ (0.1 nmol/l, 0.5 μmol/l biotin-PKC-86 peptide, and 50 μg/ml phosphatidylserine + 5 μg/ml diacylglycerol); akt1 (5.55 nmol/l, and 0.5 μmol/l biotin phospho-AKT peptide); p70 S6 kinase (1.5 nmol/l, and 0.5 μmol/l biotin-GGGKRRRLASLRA); p90 RSK2 (0.049 units/ml, and 0.5 μmol/l biotin-GGGKRRRLASLRA); c-src (4.1 units/ml, and 0.5 μmol/l biotin-KVEKIGEGTYGVVYK); Tie2 (1 μg/ml, and 200 nmol/l biotin-GGGGAPEDLYKDFLT); flt1 (1.8 nmol/l, and 0.25 μmol/l KDRY1175 [B91616] biotin-GGGGQDGKDYIVLPI-NH2); KDR (0.95 nmol/l, and 0.25 μmol/l KDRY1175 [B91616] biotin-GGGGQDGKDYIVLPI-NH2); bFGF receptor tyrosine kinase (RTK; 2 nmol/l, and 0.25 μmol/l KDRY1175 [B91616] biotin-GGGGQDGKDYIVLPI-NH2); IGF1 RTK (1.91 nmol/l, and 1 μmol/l biotin-GGGGKKKSPGEYVNIEFG-amide); insulin RTK (using DG44 IR cells); AMP kinase (470 units/ml, 50 μmol/l SAMS peptide, and 300 μmol/l AMP); pdk1 (0.25 nmol/l, 2.9 nmol/l unactivated Akt, and 20 μmol/l each of DOPC and DOPS + 2 μmol/l PIP3); CHK1 (1.4 nmol/l, and 0.5 μmol/l biotin-cdc25 peptide); CK1-ε (3 nmol/l, and 0.2 μmol/l biotin-peptide); DNA PK; and phosphatidylinositol (PI) 3-kinase (5 nmol/l, and 2 μg/ml PI). Test compounds or controls were added in 3.5 μl of DMSO, followed by 50 μl of ATP stock to yield a final concentration of 1 μmol/l ATP in all cell-free assays. After incubation, triplicate 100-μl aliquots were transferred to Combiplate eight plates (LabSystems, Helsinki, Finland) containing 100 μl/well 50 μmol/l ATP and 20 mmol/l EDTA. After 1 h, the wells were rinsed five times with PBS, filled with 200 μl of scintillation fluid, sealed, left 30 min, and counted in a scintillation counter. All steps were performed at room temperature. Inhibition was calculated as 100% × (inhibited − no enzyme control)/(DMSO control − no enzyme control).[1]

CHO-IR cells expressing human insulin receptor are grown to 80% confluence in Hamm’s F12 medium with 10% fetal bovine serum and without hypoxanthine. In 2-ml of medium devoid of fetal bovine serum, trypsinized cells are seeded in 6-well plates at a density of 1×106 cells per well. Following 24 hours, the medium is changed to 1 ml of serum-free medium containing the GSK-3 inhibitor or a control (final DMSO concentration <0.1%) for 30 min at 37°C. Lysing and centrifuging the cells for 15 min. at 4 °C/14000g. Using the filter paper assay developed by Thomas et al., the activity ratio of GS is calculated as the difference between the activity of GS in the presence and absence of 5 mmol/l glucose-6-phosphate.

[1]. Diabetes. 2003 Mar;52(3):588-95. [2]. PLoS One.2013;8(3):e58501.

Insulin resistance plays a central role in the development of type 2 diabetes, but the precise defects in insulin action remain to be elucidated. Glycogen synthase kinase 3 (GSK-3) can negatively regulate several aspects of insulin signaling, and elevated levels of GSK-3 have been reported in skeletal muscle from diabetic rodents and humans. A limited amount of information is available regarding the utility of highly selective inhibitors of GSK-3 for the modification of insulin action under conditions of insulin resistance. In the present investigation, we describe novel substituted aminopyrimidine derivatives that inhibit human GSK-3 potently (K(i) < 10 nmol/l) with at least 500-fold selectivity against 20 other protein kinases. These low molecular weight compounds activated glycogen synthase at approximately 100 nmol/l in cultured CHO cells transfected with the insulin receptor and in primary hepatocytes isolated from Sprague-Dawley rats, and at 500 nmol/l in isolated type 1 skeletal muscle of both lean Zucker and ZDF rats. It is interesting that these GSK-3 inhibitors enhanced insulin-stimulated glucose transport in type 1 skeletal muscle from the insulin-resistant ZDF rats but not from insulin-sensitive lean Zucker rats. Single oral or subcutaneous doses of the inhibitors (30-48 mg/kg) rapidly lowered blood glucose levels and improved glucose disposal after oral or intravenous glucose challenges in ZDF rats and db/db mice, without causing hypoglycemia or markedly elevating insulin. Collectively, our results suggest that these selective GSK-3 inhibitors may be useful as acute-acting therapeutics for the treatment of the insulin resistance of type 2 diabetes.[1]

---

We have identified Wnt10b as a potent inhibitor of adipogenesis that must be suppressed for preadipocytes to differentiate in vitro. Here, we demonstrate that a specific inhibitor of glycogen synthase kinase 3, CHIR 99021, mimics Wnt signaling in preadipocytes. CHIR 99021 stabilizes free cytosolic beta-catenin and inhibits adipogenesis by blocking induction of CCAAT/enhancer-binding protein alpha and peroxisome proliferator-activated receptor gamma. Preadipocyte differentiation is inhibited when 3T3-L1 cells are exposed to CHIR 99021 for any 24 h period during the first 3 days of adipogenesis. Consistent with this time frame of inhibition, expression of Wnt10b mRNA is suppressed upon induction of differentiation, with a 50% decline by 6 h and complete inhibition by 36 h. Of the agents used to induce differentiation, exposure of 3T3-L1 cells to methyl-isobutylxanthine or cAMP is sufficient to suppress expression of Wnt10b mRNA. Inhibition of adipogenesis by Wnt10b is likely mediated by Wnt receptors, Frizzled 1, 2, and/or 5, and co-receptors low density lipoprotein receptor-related proteins 5 and 6. These receptors, like Wnt10b, are highly expressed in preadipocytes and stromal vascular cells. Finally, we demonstrate that disruption of extracellular Wnt signaling by expression of secreted Frizzled related proteins causes spontaneous adipocyte conversion.[2]

---

Recent developments indicate that the regeneration of beta cell function and mass in patients with diabetes is possible. A regenerative approach may represent an alternative treatment option relative to current diabetes therapies that fail to provide optimal glycemic control. Here we report that the inactivation of GSK3 by small molecule inhibitors or RNA interference stimulates replication of INS-1E rat insulinoma cells. Specific and potent GSK3 inhibitors also alleviate the toxic effects of high concentrations of glucose and the saturated fatty acid palmitate on INS-1E cells. Furthermore, treatment of isolated rat islets with structurally diverse small molecule GSK3 inhibitors increases the rate beta cell replication by 2-3-fold relative to controls. We propose that GSK3 is a regulator of beta cell replication and survival. Moreover, our results suggest that specific inhibitors of GSK3 may have practical applications in beta cell regenerative therapies.[3]

C22H20CL4N8

538.26

538.053

C, 49.09; H, 3.75; Cl, 26.34; N, 20.82

2109414-84-6

252917-06-9;1782235-14-6 (3HCl);2109414-84-6 (2HCl);1797989-42-4 (HCl);

91826519

Solid powder

5

7

7

34

645

0

OOMHEMQQCHEWDS-UHFFFAOYSA-N

InChI=1S/C22H18Cl2N8.2ClH/c1-13-10-29-21(31-13)17-12-30-22(32-20(17)16-4-3-15(23)8-18(16)24)27-7-6-26-19-5-2-14(9-25)11-28-19;;/h2-5,8,10-12H,6-7H2,1H3,(H,26,28)(H,29,31)(H,27,30,32);2*1H

6-((2-((4-(2,4-dichlorophenyl)-5-(5-methyl-1H-imidazol-2-yl)pyrimidin-2-yl)amino)ethyl)amino)nicotinonitrile dihydrochloride

2109414-84-6; UNII-X6BE5J2G31; Laduviglusib dihydrochloride; CHIR-99021 dihydrochloride; CHIR-911 dihydrochloride;

2934.99.9001

Powder      -20°C    3 years

                     4°C     2 years

In solvent   -80°C    6 months

                  -20°C    1 month

Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

Typically soluble in DMSO (e.g. > 10 mM)

Note: Listed below are some common formulations that may be used to formulate products with low water solubility (e.g. < 1 mg/mL), you may test these formulations using a minute amount of products to avoid loss of samples.

---

Injection Formulation 1: DMSO : Tween 80： Saline = 10 : 5 : 85 (i.e. 100 μL DMSO stock solution → 50 μL Tween 80 → 850 μL Saline)
*Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH ₂ O to obtain a clear solution.
Injection Formulation 2: DMSO : PEG300 ：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL DMSO → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline)
Injection Formulation 3: DMSO : Corn oil = 10 : 90 (i.e. 100 μL DMSO → 900 μL Corn oil)
Example: Take the Injection Formulation 3 (DMSO : Corn oil = 10 : 90) as an example, if 1 mL of 2.5 mg/mL working solution is to be prepared, you can take 100 μL 25 mg/mL DMSO stock solution and add to 900 μL corn oil, mix well to obtain a clear or suspension solution (2.5 mg/mL, ready for use in animals).

View More

Injection Formulation 4: DMSO : 20% SBE-β-CD in saline = 10 : 90 [i.e. 100 μL DMSO → 900 μL (20% SBE-β-CD in saline)]
*Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution.
Injection Formulation 5: 2-Hydroxypropyl-β-cyclodextrin : Saline = 50 : 50 (i.e. 500 μL 2-Hydroxypropyl-β-cyclodextrin → 500 μL Saline)
Injection Formulation 6: DMSO : PEG300 : castor oil : Saline = 5 : 10 : 20 : 65 (i.e. 50 μL DMSO → 100 μLPEG300 → 200 μL castor oil → 650 μL Saline)
Injection Formulation 7: Ethanol : Cremophor : Saline = 10： 10 : 80 (i.e. 100 μL Ethanol → 100 μL Cremophor → 800 μL Saline)
Injection Formulation 8: Dissolve in Cremophor/Ethanol (50 : 50), then diluted by Saline
Injection Formulation 9: EtOH : Corn oil = 10 : 90 (i.e. 100 μL EtOH → 900 μL Corn oil)
Injection Formulation 10: EtOH : PEG300：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL EtOH → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline)

---

Oral Formulation 1: Suspend in 0.5% CMC Na (carboxymethylcellulose sodium)
Oral Formulation 2: Suspend in 0.5% Carboxymethyl cellulose
Example: Take the Oral Formulation 1 (Suspend in 0.5% CMC Na) as an example, if 100 mL of 2.5 mg/mL working solution is to be prepared, you can first prepare 0.5% CMC Na solution by measuring 0.5 g CMC Na and dissolve it in 100 mL ddH2O to obtain a clear solution; then add 250 mg of the product to 100 mL 0.5% CMC Na solution, to make the suspension solution (2.5 mg/mL, ready for use in animals).

View More

Oral Formulation 3: Dissolved in PEG400
Oral Formulation 4: Suspend in 0.2% Carboxymethyl cellulose
Oral Formulation 5: Dissolve in 0.25% Tween 80 and 0.5% Carboxymethyl cellulose
Oral Formulation 6: Mixing with food powders

---

Note: Please be aware that the above formulations are for reference only. InvivoChem strongly recommends customers to read literature methods/protocols carefully before determining which formulation you should use for in vivo studies, as different compounds have different solubility properties and have to be formulated differently.

---

 (Please use freshly prepared in vivo formulations for optimal results.)
