yingweiwo

(R)-BAY1238097

Alias: R-isomer of BAY-1238097; BAY1238097; BAY-1238097; BAY 1238097; BAY 12-38097; BAY 123; BAY-123; BAY12-38097; BAY-12-38097
Cat No.:V4201 Purity: ≥98%
R)-BAY1238097 is the R-isomer of BAY-1238097 with lower activity than BAY1238097.
(R)-BAY1238097
(R)-BAY1238097 Chemical Structure CAS No.: 1564269-85-7
Product category: Epigenetic Reader Domain
This product is for research use only, not for human use. We do not sell to patients.
Size Price Stock Qty
5mg
10mg
25mg
50mg
100mg
250mg
Other Sizes

Other Forms of (R)-BAY1238097:

  • BAY-1238097
Official Supplier of:
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Alternate Text
Top Publications Citing lnvivochem Products
Purity & Quality Control Documentation

Purity: ≥98%

Product Description

(R)-BAY1238097 is the R-isomer of BAY-1238097 with lower activity than BAY1238097. BAY1238097 is a novel, potent and selective inhibitor of BET (bromodomain and extra-terminal) binding to histones and targeting the NFKB/TLR/JAK/STAT signalling pathways, MYC and E2F1-regulated genes, cell cycle regulation and chromatin structure. It has strong anti-proliferative activity in different AML (acute myeloid leukemia) and MM (multiple myeloma) models through down-regulation of c-Myc levels and its downstream transcriptome (IC50 <100 nM in a TR-FRET assay). In vitro, BAY 1238097 showed strong inhibitory activity (IC50 < 100 nM) in a TR-FRET assay using BET BRD4 bromodomain 1 and an acetylated peptide derived from histone H4. In the NanoBRET assay, the interaction between BRD4, BRD3 or BRD2 and H4 was inhibited with IC50 values of 63 nM, 609 nM and 2430 nM, showing selectivity of the compound for BRD4. A strong reduction of c-Myc transcript and protein levels was observed in treated MOLM-13 (AML) and MOLP-8 (MM) cell lines. ChIP experiments performed in these models additionally revealed that BAY 1238097 prevented binding of BRD4 to c-Myc regulatory regions. In vivo, BAY 1238097 showed strong efficacy in the AML models THP-1, MOLM-13 and KG-1, with T/C between 13 and 20%. Overall, the compound was well tolerated at MTD, with body weight losses of 5-9% at nadir. BAY 1238097 was also active in MM models. Efficacy was observed against a human IGH-cyclin D1 translocated MOLP-8 model with a T/C of 3%, whereas the standard-of-care agents bortezomib and lenalidomide were inactive or poorly active. In this model, BAY 1238097 was well tolerated at 10 mg/kg applied over 14 days, with no body weight loss measured. BAY 1238097 was also active against the FGFR/MMSET translocated model NCIH929, with 19% T/C versus 49% T/C for the standard-of-care lenalidomide. The compound was well tolerated applied at 12 mg/kg for 9 days (maximum body weight loss 6%).

Biological Activity I Assay Protocols (From Reference)
ln Vitro
In vitro, BAY 1238097 showed strong inhibitory activity (IC50 < 100 nM) in a TR-FRET assay using BET BRD4 bromodomain 1 and an acetylated peptide derived from histone H4. In the NanoBRET assay, the interaction between BRD4, BRD3 or BRD2 and H4 was inhibited with IC50 values of 63 nM, 609 nM and 2430 nM, showing selectivity of the compound for BRD4. A strong reduction of c-Myc transcript and protein levels was observed in treated MOLM-13 (AML) and MOLP-8 (MM) cell lines. ChIP experiments performed in these models additionally revealed that BAY 1238097 prevented binding of BRD4 to c-Myc regulatory regions.
ln Vivo
In vivo, BAY 1238097 showed strong efficacy in the AML models THP-1, MOLM-13 and KG-1, with T/C between 13 and 20%. Overall, the compound was well tolerated at MTD, with body weight losses of 5-9% at nadir. BAY 1238097 was also active in MM models. Efficacy was observed against a human IGH-cyclin D1 translocated MOLP-8 model with a T/C of 3%, whereas the standard-of-care agents bortezomib and lenalidomide were inactive or poorly active. In this model, BAY 1238097 was well tolerated at 10 mg/kg applied over 14 days, with no body weight loss measured. BAY 1238097 was also active against the FGFR/MMSET translocated model NCIH929, with 19% T/C versus 49% T/C for the standard-of-care lenalidomide. The compound was well tolerated applied at 12 mg/kg for 9 days (maximum body weight loss 6%).
Gene expression profiling performed in liver, blood and duodenum of rats treated daily with 2 mg/kg BAY 1238097 for 14 days demonstrated substantial effects on genes involved in cell proliferation and in the immune response in vivo.
References

[1]. (2015) Abstract 3524: BAY 1238097, a novel BET inhibitor with strong efficacy in hematological tumor models. Cancer Research, 75(15 Suppl), 884.

[2]. Preclinical evaluation of the BET bromodomain inhibitor BAY 1238097 for the treatment of lymphoma. Br J Haematol. 2017 Sep;178(6):936-948.

These protocols are for reference only. InvivoChem does not independently validate these methods.
Physicochemical Properties
Molecular Formula
C25H33N5O3
Molecular Weight
451.56
Exact Mass
451.258
CAS #
1564269-85-7
Related CAS #
BAY1238097;1564268-08-1
PubChem CID
90041345
Appearance
Light yellow to yellow solid powder
LogP
2.4
Hydrogen Bond Donor Count
1
Hydrogen Bond Acceptor Count
6
Rotatable Bond Count
4
Heavy Atom Count
33
Complexity
688
Defined Atom Stereocenter Count
1
SMILES
C1CN(C)CCN1C1=CC=C(C=C1)C1=NN(C(=O)NC)[C@@H](CC2C1=CC(=C(C=2)OC)OC)C
InChi Key
CJIPEACKIJJYED-KRWDZBQOSA-N
InChi Code
InChI=1R/C25H33N5O3/c1-17-14-19-15-22(32-4)23(33-5)16-21(19)24(27-30(17)25(31)26-2)18-6-8-20(9-7-18)29-12-10-28(3)11-13-29/h6-9,15-17H,10-14H2,1-5H3,(H,26,31)/t17-/m0/s1
Chemical Name
(R)-7,8-dimethoxy-N,4-dimethyl-1-(4-(4-methylpiperazin-1-yl)phenyl)-4,5-dihydro-3H-benzo[d][1,2]diazepine-3-carboxamide
Synonyms
R-isomer of BAY-1238097; BAY1238097; BAY-1238097; BAY 1238097; BAY 12-38097; BAY 123; BAY-123; BAY12-38097; BAY-12-38097
HS Tariff Code
2934.99.9001
Storage

Powder      -20°C    3 years

                     4°C     2 years

In solvent   -80°C    6 months

                  -20°C    1 month

Note: Please store this product in a sealed and protected environment (e.g. under nitrogen), avoid exposure to moisture.
Shipping Condition
Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)
Solubility Data
Solubility (In Vitro)
DMSO : ~150 mg/mL (~332.18 mM)
Solubility (In Vivo)
Solubility in Formulation 1: ≥ 2.5 mg/mL (5.54 mM) (saturation unknown) in 10% DMSO + 40% PEG300 + 5% Tween80 + 45% Saline (add these co-solvents sequentially from left to right, and one by one), clear solution.
For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 25.0 mg/mL clear DMSO stock solution to 400 μL PEG300 and mix evenly; then add 50 μL Tween-80 to the above solution and mix evenly; then add 450 μL normal saline to adjust the volume to 1 mL.
Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH₂ O to obtain a clear solution.

Solubility in Formulation 2: ≥ 2.5 mg/mL (5.54 mM) (saturation unknown) in 10% DMSO + 90% Corn Oil (add these co-solvents sequentially from left to right, and one by one), clear solution.
For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 25.0 mg/mL clear DMSO stock solution to 900 μL of corn oil and mix evenly.

 (Please use freshly prepared in vivo formulations for optimal results.)
Preparing Stock Solutions 1 mg 5 mg 10 mg
1 mM 2.2145 mL 11.0727 mL 22.1455 mL
5 mM 0.4429 mL 2.2145 mL 4.4291 mL
10 mM 0.2215 mL 1.1073 mL 2.2145 mL

*Note: Please select an appropriate solvent for the preparation of stock solution based on your experiment needs. For most products, DMSO can be used for preparing stock solutions (e.g. 5 mM, 10 mM, or 20 mM concentration); some products with high aqueous solubility may be dissolved in water directly. Solubility information is available at the above Solubility Data section. Once the stock solution is prepared, aliquot it to routine usage volumes and store at -20°C or -80°C. Avoid repeated freeze and thaw cycles.

Calculator

Molarity Calculator allows you to calculate the mass, volume, and/or concentration required for a solution, as detailed below:

  • Calculate the Mass of a compound required to prepare a solution of known volume and concentration
  • Calculate the Volume of solution required to dissolve a compound of known mass to a desired concentration
  • Calculate the Concentration of a solution resulting from a known mass of compound in a specific volume
An example of molarity calculation using the molarity calculator is shown below:
What is the mass of compound required to make a 10 mM stock solution in 5 ml of DMSO given that the molecular weight of the compound is 350.26 g/mol?
  • Enter 350.26 in the Molecular Weight (MW) box
  • Enter 10 in the Concentration box and choose the correct unit (mM)
  • Enter 5 in the Volume box and choose the correct unit (mL)
  • Click the “Calculate” button
  • The answer of 17.513 mg appears in the Mass box. In a similar way, you may calculate the volume and concentration.

Dilution Calculator allows you to calculate how to dilute a stock solution of known concentrations. For example, you may Enter C1, C2 & V2 to calculate V1, as detailed below:

What volume of a given 10 mM stock solution is required to make 25 ml of a 25 μM solution?
Using the equation C1V1 = C2V2, where C1=10 mM, C2=25 μM, V2=25 ml and V1 is the unknown:
  • Enter 10 into the Concentration (Start) box and choose the correct unit (mM)
  • Enter 25 into the Concentration (End) box and select the correct unit (mM)
  • Enter 25 into the Volume (End) box and choose the correct unit (mL)
  • Click the “Calculate” button
  • The answer of 62.5 μL (0.1 ml) appears in the Volume (Start) box
g/mol

Molecular Weight Calculator allows you to calculate the molar mass and elemental composition of a compound, as detailed below:

Note: Chemical formula is case sensitive: C12H18N3O4  c12h18n3o4
Instructions to calculate molar mass (molecular weight) of a chemical compound:
  • To calculate molar mass of a chemical compound, please enter the chemical/molecular formula and click the “Calculate’ button.
Definitions of molecular mass, molecular weight, molar mass and molar weight:
  • Molecular mass (or molecular weight) is the mass of one molecule of a substance and is expressed in the unified atomic mass units (u). (1 u is equal to 1/12 the mass of one atom of carbon-12)
  • Molar mass (molar weight) is the mass of one mole of a substance and is expressed in g/mol.
/

Reconstitution Calculator allows you to calculate the volume of solvent required to reconstitute your vial.

  • Enter the mass of the reagent and the desired reconstitution concentration as well as the correct units
  • Click the “Calculate” button
  • The answer appears in the Volume (to add to vial) box
In vivo Formulation Calculator (Clear solution)
Step 1: Enter information below (Recommended: An additional animal to make allowance for loss during the experiment)
Step 2: Enter in vivo formulation (This is only a calculator, not the exact formulation for a specific product. Please contact us first if there is no in vivo formulation in the solubility section.)
+
+
+

Calculation results

Working concentration mg/mL;

Method for preparing DMSO stock solution mg drug pre-dissolved in μL DMSO (stock solution concentration mg/mL). Please contact us first if the concentration exceeds the DMSO solubility of the batch of drug.

Method for preparing in vivo formulation:Take μL DMSO stock solution, next add μL PEG300, mix and clarify, next addμL Tween 80, mix and clarify, next add μL ddH2O,mix and clarify.

(1) Please be sure that the solution is clear before the addition of next solvent. Dissolution methods like vortex, ultrasound or warming and heat may be used to aid dissolving.
             (2) Be sure to add the solvent(s) in order.
